QINDING pieces of in situ crushing bucket is suitable for inert material is the first product in the category on the
market, to maximize the use of excavator hydraulic system.
Wide field of application: demolition, construction, industrial and landskommun products processing, civil
engineering, road planning, mining operations, rock, mining and dredging operations.
1. Robust Construction
- Fabricated with high-strength steel and full-penetration welding. Reinforced with stiffener plates at critical stress points, improving impact resistance.
- Curved profile minimizes material adhesion for cleaner dumping.
2. Superior Wear Resistance
- Base reinforced with wear-resistant steel cutting edge, optional tungsten carbide teeth/side cutters for 3x longer lifespan vs. standard buckets.
TYPE | MATERIAL | G.E.T | APPLICATION |
GD Bucket | Q345B | Adapter,Teeth,Side cutter | Mainly used for excavation and sand, gravel and
soil and other light load operating environment. |
HD Bucket | Q345B | Adapter,Teeth,Side cutter | Mainly used for digging hard soil, mixed with a
relative soft stone and clay, softer stones and
other light load operating environment. |
SD Bucket | Q345 & NM400 | Adapter,Teeth,Side cutter/
protector | Mainly used for mining hard gravel mixed with
hard soil, sub-hard stone or flint, after
blasting or loading, and heavy-loading. |
XD Bucket | Q345 & NM400
/HARDOX450
/HARDOX500 | Adapter,Teeth,Side protector,Corner shrouds | Mainly used for very high abrasion conditions
including high quartzite granite,broken slag,
sandstone and ore. |
Mini Bucket | Q345B | Adapter,Teeth,Side cutter | Used for light work environments with small
excavators. |
Trench Bucket | Q345B | Adapter,Teeth,Side cutter | Used for rivers, ponds and ditches environment. |
Cleaning Bucket | Q345B & NM400 | \ | Applied to cleaning work in channels and ditches. |
Skeleton Bucket | Q345B & NM400 | Adapter,Teeth,Side cutter/
protector | Applied in integrating sieving and excavation
of relatively loose materials. |
