QINDING pieces of in situ crushing bucket is suitable for inert material is the first product in the category on the
market, to maximize the use of excavator hydraulic system.
Wide field of application: demolition, construction, industrial and landskommun products processing, civil
engineering, road planning, mining operations, rock, mining and dredging operations.
1. Robust Construction
- Fabricated with high-strength steel and full-penetration welding. Reinforced with stiffener plates at critical stress points, improving impact resistance.
- Curved profile minimizes material adhesion for cleaner dumping.
2. Superior Wear Resistance
- Base reinforced with wear-resistant steel cutting edge, optional tungsten carbide teeth/side cutters for 3x longer lifespan vs. standard buckets.
Model | QDG03 | QDG04 | QDG06 | QDG08 | QDG10 | QDG14 | QDG20 |
Weight(kg) | 450 | 680 | 780 | 1190 | 1780 | 2100 | 2400 |
Max jaw opening(m/m) | 1100 | 1400 | 1800 | 2300 | 2500 | 2650 | 2700 |
Oil pressure(kg/cm2) | 160-180 | 160-180 | 160-180 | 160-180 | 160-180 | 180-200 | 180-200 |
Set up pressure(kg/cm2) | 200 | 200 | 200 | 200 | 210 | 220 | 250 |
Operating flux(lpm) | 100-140 | 100-140 | 100-140 | 100-140 | 130-170 | 180-250 | 250-320 |
Unloading quality | 1000 | 2000 | 3000 | 5000 | 8000 | 10000 | 10000 |
